Intel
®
Entry Server Chassis SC5299-E TPS Product Overview
Revision 3.1
Intel order number D37594-005
3
Configuration SC5299UP SC5299DP SC5299BRP SC5299WS
connectors
Color Black
Construction 1.0-mm, zinc-plated sheet metal, meets Intel Cosmetic Spec # C25432
Chassis ABS Fire retardant, non- brominated, PC-ABS
Dimensions
Pedestal
17.8 in (45.2 cm) x 9.256 in (23.5 cm) x 19 in (48.3 cm)
Dimensions
Rack
9.256 in (23.5 cm) x 17.6 in (44.7 cm) x 19 in (48.3 cm)
1.2 Chassis Views
TP01717
A
D
B
C
E
F
A. Control panel controls and indicators
B. Two half-height 5.25-in peripheral drive bays
C. 3.5-in removable media drive bay
D. Internal hard drive bay cage (behind door)
E. Security lock
F. USB ports
Figure 1. Front Closed Chassis View of Intel
®
