Intel SC5299BRP User Manual

Intel
®
Entry Server Chassis SC5299-E TPS Power Sub-system
Revision 3.1
Intel order number D37594-005
67
2.4.2.4 Processor Power Connector (P2)
Connector housing: 8-Pin Molex* 39-01-2080 or equivalent
Contact: Molex Mini-Fit, HCS, Female, Molex
44476 or equivalent
Table 76. P2 Processor Power Connector
Pin Signal 18 AWG Color Pin Signal 18 AWG Color
1 COM Black 5 +12V1 White
2 COM Black 6 +12V1 White
3 COM Black 7 +12V2 Brown
4 COM Black 8 +12V2 Brown
2.4.2.5 12V4 Power Connector (P13)
Connector housing: 8-Pin Molex* 39-01-2040 or equivalent
Contact: Molex Mini-Fit Jr, HCS,
44476-1111 or equivalent
Table 77. P13 12V4 Power Connector
Pin Signal 18 AWG Color Pin Signal 18 AWG Color
1 COM Black 3 +12V4 Green
2 COM Black 4 +12V4 Green
2.4.2.6 Power Signal Connector (P12)
Connector housing: 5-Pin Molex* 50-57-9405 or equivalent
Contacts: Molex 16-02-0087 or equivalent
Table 78. Power Signal Connector
Pin Signal 24 AWG Color
1 I2C Clock White
2 I2C Data Yellow
3 SMBAlert# TBD
4 COM Black
5 3.3RS Orange
