Entry Server Chassis SC5299-E TPS Power Sub-system
Revision 3.1
Intel order number D37594-005
83
The power supply meets UL enclosure requirements for temperature rise limits. All sides of the
power supply, with exception of the air exhaust side, are classified as “Handle, knobs, grips,
etc., held for short periods of time only.”
2.5.5 Output Wire Harness Drawing
Listed or recognized component appliance wiring material (AVLV2), CN, rated min 105 C,
300VDC is used for all output wiring.
Table 99. Cable Lengths
From
Length
(mm)
To Connector
#
Number of
Pins
Description
Power Supply cover exit hole 425 P1 24 Baseboard Power Connector
Power Supply cover exit hole 680 P2 8 Processor Power Connector
Power Supply cover exit hole 375 P14 5 Power Signal Connector
Power Supply cover exit hole 375 P15 6 PCI Express Connector
Power Supply cover exit hole 680 P16 4 12V4 Power Connector
Power Supply cover exit hole 450 P3 4 Peripheral Power Connector
Extension 100 P4 4 Peripheral Power Connector
Extension from P4 100 P5 4 Floppy Power Connector
Power Supply cover exit hole 575 P6 4 Peripheral Power Connector
Extension
75 (cover with
sleeve)
P7 4
Right-angle Peripheral Power
Connector
Power Supply cover exit hole 740 P8 4 Peripheral Power Connector
Extension 75 P9 4 Peripheral Power Connector
Power Supply cover exit hole 740 P10 4 Peripheral Power Connector
Extension 75 P11 4 Peripheral Power Connector
Power Supply cover exit hole 740 P12 5 Right-angle SATA Power Connector
Extension 75 P13 5 SATA Power Connector
