Entry Server Chassis SC5299-E TPS Power Sub-system
Revision 3.1
Intel order number D37594-005
23
Table 19. PSON# Signal Characteristic
Signal Type
Accepts an open collector/drain input from the system.
Pull-up to 5V located in power supply.
PSON
#
= Low ON
PSON
#
= High or Open OFF
MIN MAX
Logic level low (power supply ON) 0V 1.0V
Logic level high (power supply OFF) 2.0V 5.25V
Source current, Vpson = low 4mA
Power up delay: T
pson_on_delay
5msec 400msec
PWOK delay: T
pson_pwok
50msec
2.1.6.5 PWOK (Power OK) Output Signal
PWOK is a power OK signal and is pulled HIGH by the power supply to indicate that all the
outputs are within the regulation limits of the power supply. When any output voltage falls below
regulation limits or when AC power has been removed for a time sufficiently long that the power
supply operation is no longer guaranteed, PWOK will be de-asserted to a LOW state. The start
of the PWOK delay time is inhibited as long as any power supply output is within current limit.
Table 20. PWOK Signal Characteristics
Signal Type
Open collector/drain output from power supply. Pull-up
to VSB located in system.
PWOK = High Power OK
PWOK = Low Power Not OK
MIN MAX
Logic level low voltage, Isink=4mA 0V 0.4V
Logic level high voltage, Isource=200 A
2.4V 5.25V
Sink current, PWOK = low 4mA
Source current, PWOK = high 2mA
PWOK delay: T
pwok_on
100ms 1000ms
PWOK rise and fall time
100 sec
Power down delay: T
pwok_off
1ms 200msec
