Entry Server Chassis SC5299-E TPS Power Sub-system
Revision 3.1
Intel order number D37594-005
87
2.5.6.4 12V4 Power Connector (P16)
Connector housing: 6-Pin Molex* 39-01-2040 or equivalent
Contacts: Molex Mini-Fit, HCS, 44476-1111 or equivalent
Table 103. 12V4 Power Connector
Pin Signal 18 AWG Color Pin Signal 18 AWG Color
1 COM Black 4 +12V4 Green
2 COM Black 5 +12V4 Green
2.5.6.5 PCI Express Connector (P15)
Connector housing: 6-Pin Mole* 455590002 or equivalent
Contacts: Molex Mini-Fit, HCS, Female, Crimp 44476
Table 104. PCI Express Connector
Pin Signal 18 AWG Color Pin Signal 18 AWG Color
1 +12V4 Green 4 COM Black
2 +12V4 Green 5 COM Black
3 +12V4 Green 6 COM Black
2.5.6.6 Peripheral Power Connectors (P3, P4, P6, P8-P11)
Connector housing: Amp* 1-480424-0 or equivalent
Contact: Amp 61314-1 contact or equivalent
Table 105. Peripheral Power Connectors
Pin Signal 18 AWG Color
1 +12 V4 Green
2 COM Black
3 COM Black
4 +5 VDC Red
2.5.6.7 Right-angle Peripheral Power Connector (P7)
Connector housing: JWT* F6001HS2-4P or equivalent.
