Intel SC5299BRP User Manual

Peripheral and Hard Drive Support Intel
®
Entry Server Chassis SC5299-E TPS
Revision 3.1
Intel order number D37594-005
116
Connector Contact
Number
Signal Name
6 H_RXPn
7 GND
8 3.3V - NC
9 3.3V - NC
10 3.3V Precharge - NC
11 GND
12 GND
13 GND
14 5V Precharge
15 5V
16 5V
17 GND
18
19 GND
20 12V Precharge
21 12V
22 12V
G1 GND
G2 GND
4.3.2.8 Power Connectors
The 6HDD SATA HSBP provides two standard 4-pin hard drive power connectors. The following
table defines the pin-out of the 4-pin power connectors (JP4 and JP5).
Table 135. Power Connector Pin-out
Pin Signal
1 12V
2 GND
3 GND
4 5V
