Entry Server Chassis SC5299-E TPS Power Sub-system
Revision 3.1
Intel order number D37594-005
63
2.4.1 Mechanical Overview
Figure 14. Mechanical Drawing for Dual (1+1 Configuration) Power Supply Enclosure
2.4.1.1 Airflow Requirements
There is no fan in the cage; the cage is cooled by the fan in the power supply module(s) when
combined together in the system.
2.4.1.2 Temperature Requirements
The PDB operates within all specified limits over the T
op
temperature range.
Table 72. Environmental Requirements
Item Description MIN MAX Units
T
op
Operating temperature range. 0 45
C
