Entry Server Chassis SC5299-E TPS Power Sub-system
Revision 3.1
Intel order number D37594-005
65
Connector Upper Side Pin No
Top.
Pin No.
Bottom
Bottom Side
+12V Return 35 36 +12V Return
5VSB 37 38 A0
SDA 39 40 +12V Sharing
PS_KILL 41 42 POK
PS_ON_CTL 43 44 -PS_Present
FAN_TACH 45 46 VIN_GOOD_OUT
SCL 47 48 -OVER_TEMP
The AC input for each power supply module connects through the card edge connector from the
power distribution board to the power supply module.
2.4.2.2 Output Connectors
Listed or recognized component appliance wiring material (AVLV2), CN, rated min 105 degrees
C, 300VDC is used for all output wiring.
Table 74. Cable Lengths
From
Length
(mm)
To Connector
#
Number of
Pins
Description
Power Supply cover exit hole 450 P1 24 Baseboard Power Connector
Power Supply cover exit hole 580 P2 8 Processor Power Connector
Power Supply cover exit hole 450 P12 5 Power Signal Connector
Power Supply cover exit hole 550 P13 4 12V4 Power Connector
Power Supply cover exit hole 290 P3 4 Peripheral Power Connector
Extension from P3 100 P4 4 Peripheral Power Connector
Extension from P4 100 P5 4 Floppy Power Connector
Power Supply cover exit hole 740 P6 4 Peripheral Power Connector
Extension 75 P7 4 Peripheral Power Connector
Power Supply cover exit hole 740 P8 4 Peripheral Power Connector
Extension 75 P9 4 Peripheral Power Connector
Power Supply cover exit hole 740 P10 5 Right-angle SATA Power Connector
Extension 75 P11 5 Right-angle SATA Power Connector
