Power Sub-system Intel
®
Entry Server Chassis SC5299-E TPS
Revision 3.1
Intel order number D37594-005
34
2.2.4.6 P5 Floppy Power Connector
Connector housing: AMP* 171822-4 or equivalent
Contact: Amp 170204-1 contact or equivalent
Table 34. P5 Floppy Power Connector
Pin Signal 22 AWG Color
1 +5VDC Red
2 COM Black
3 COM Black
4 +12V2 Green
2.2.4.7 P10 Right-angle SATA Power Connector
Connector housing: JWT* F6002HS0-5P-18 or equivalent
Table 35. P10 SATA Power Connectors
Pin Signal 18 AWG Color
1 +3.3V Orange
2 COM Black
3 +5VDC Red
4 COM Black
5 +12V2 Green
2.2.4.8 P11 SATA Power Connector
Connector housing: JWT A3811H00-5P or equivalent
Contact: JWT A3811TOP-0D or equivalent
Table 36. P11 SATA Power Connectors
Pin Signal 18 AWG Color
1 +3.3V Orange
2 COM Black
3 +5VDC Red
