Intel SC5299BRP User Manual

Power Sub-system Intel
®
Entry Server Chassis SC5299-E TPS
Revision 3.1
Intel order number D37594-005
86
2.5.6.2 Processor Power Connector (P2)
Connector housing: 8-Pin Molex* 39-01-2080 or equivalent
Contact: Molex
44476-1111 or equivalent
Table 101. P2 Processor Power Connector
Pin Signal 18 AWG Color Pin Signal 18 AWG Color
1 COM Black 5 +12V1 White
2 COM Black 12V1 RS Yellow (24 AWG)
3 COM Black 6 +12V1 White
4 COM Black 7 +12V2 Brown
8 +12V2 Brown
2.5.6.3 Power Signal Connector (P14)
Connector housing: 5-Pin Molex* 50-57-9405 or equivalent
Contacts: Molex 16-02-0087 or equivalent
Table 102. Power Signal Connector
Pin Signal 24 AWG Color
1 I
2
C Clock White
2 I
2
C Data Yellow
3 Reserved N.C.
4 COM Black
5 3.3RS Orange
