Intel
®
Entry Server Chassis SC5299-E TPS Intel
®
Local Control Panel
Revision 3.1
Intel order number D37594-005
123
6.1 Internal Control Panel Headers
The control panel interface board has one internal header:
A 4-pin header provides control and status information to/from the server board via the
IPMB interface. A 4-pin round cable connects the iLCP to the server board.
The following table provides the pin-out for each of these headers:
Table 140. IPMI Header
Pin # Description
1 IPMB_5VSB_SDA
2 GND
3 IPMB_5VSB_SCL
4 P5V_STBY
