Power Sub-system Intel
®
Entry Server Chassis SC5299-E TPS
Revision 3.1
Intel order number D37594-005
68
2.4.2.7 Peripheral Power Connectors (P3, P4, P6, P7, P8, P9)
Connector housing: Amp* 1-480424-0 or equivalent
Contact: Amp 61314-1 contact or equivalent
Table 79. Peripheral Power Connectors
Pin Signal 18 AWG Color
1 +12V4 Green
2 COM Black
3 COM Black
4 +5 VDC Red
2.4.2.8 Floppy Power Connector (P5)
Connector housing: Amp* 171822-4 or equivalent
Contact: Amp 170204-1 contact or equivalent
Table 80. Floppy Power Connector
Pin Signal 22 AWG Color
1 +5VDC Red
2 COM Black
3 COM Black
4 +12V4 Green
2.4.2.9 12V4 Power Connector (P6)
Connector housing: 4-Pin Molex* 39-01-2040 or equivalent
Contact: Molex Mini-Fit Jr, HCS, 44476-1111 or equivalent
Table 81. 12V4 Power Connector
Pin Signal 18 AWG Color
1 COM Black
2 COM Black
3 +12V4 Green
5 +12V4 Green
2.4.2.10 Right-angle SATA Power Connectors (P10, P11)
Connector housing: JWT* F6002HS0-5P-18 or equivalent
