Power Sub-system Intel
®
Entry Server Chassis SC5299-E TPS
Revision 3.1
Intel order number D37594-005
18
2.1.5.5 Voltage Regulation
The power supply output voltages are within the following voltage limits when operating at
steady state and dynamic loading conditions. These limits include the peak-peak ripple/noise.
All outputs are measured with reference to the return remote sense signal (ReturnS). The 5V,
12V1, 12V2, –12V and 5VSB outputs are measured at the power supply connectors referenced
to ReturnS. The +3.3V is measured at the remote sense signal (3.3VS) located at the signal
connector.
Table 12. Voltage Regulation Limits
Parameter Tolerance MIN NOM MAX Units
+ 3.3V - 5%/+5% +3.135 +3.30 +3.47 V
rms
+ 5V - 4%/+5% +4.80 +5.00 +5.25 V
rms
+ 12V1 - 5%/+5% +11.40 +12.00 +12.60 V
rms
+ 12V2 - 5%/+5% +11.40 +12.00 +12.60 V
rms
- 12V - 5%/+4% -11.52 -12.00 -12.60 V
rms
+ 5VSB - 4%/+5% +4.80 +5.00 +5.25 V
rms
2.1.5.6 Dynamic Loading
The output voltages are within limits specified for the step loading and capacitive loading
specified in the following table. The step load may occur anywhere within the MIN load to the
MAX load conditions.
Table 13. Transient Load Requirements
Parameter Output Range MAX Step Voltage Overshoot/Undershoot
+12V1DC 0.5A TO 18A 6A
350mV (700mVpk-pk)
+12V2DC 0.5A TO 15A 6A
350mV (700mVpk-pk)
+5VDC 2A TO 20A 5A
200mV(400mVpk-pk)
+3.3VDC 0.5A TO 17A 6A
200mV (400mVpk-pk)
+5VSB 0.1A TO 2.0A 0.7A
250mV(500mVpk-pk)
