Intel SC5299BRP User Manual

Power Sub-system Intel
®
Entry Server Chassis SC5299-E TPS
Revision 3.1
Intel order number D37594-005
32
Table 29. Cable Lengths
From Length (mm)
To
Connector #
Number of
Pins
Description
Power Supply cover exit hole 425 P1 24 Baseboard Power Connector
Power Supply cover exit hole 720 P2 8 Processor Power Connector
Power Supply cover exit hole 575 P12 4 +12V1 Baseboard Power Connector
Power Supply cover exit hole 250 P3 4 Peripheral Power Connector
Extension from P3 100 P4 4 Peripheral Power Connector
Extension from P4 100 P5 4 Floppy Power Connector
Power Supply cover exit hole 740 P6 4 Peripheral Power Connector
Extension from P8 75 P7 4 Peripheral Power Connector
Power Supply cover exit hole 740 P8 4 Peripheral Power Connector
Extension from P10 75 P9 4 Peripheral Power Connector
Power Supply cover exit hole 740 P10 5 Right-angle SATA Power Connector
Extension from P12 75 P11 5 SATA Power Connector
2.2.4.2 P1 Main Power Connector
Connector housing: 24-Pin Molex* Mini-Fit Jr.
39-01-2245 or equivalent
Contact: Molex Mini-Fit, HCS, Female, Crimp 44476 or equivalent
Table 30. P1 Main Power Connector
Pin Signal 18 AWG Color Pin Signal 18 AWG Color
1 +3.3 VDC Orange 13 +3.3 VDC* Orange
3.3RS Orange/White(24AWG) 14 -12 VDC Blue
2 +3.3 VDC Orange 15 COM Black
3 COM Black 16 PSON# Green (24AWG)
4 +5 VDC Red 17 COM Black
5 COM Black COMRS Black (24AWG)
6 +5 VDC Red 18 COM Black
7 COM Black 19 COM Black
8 PWR OK Gray 20 Reserved N.C.
9 5VSB Purple 21 +5 VDC Red
10 +12V2 Yellow 22 +5 VDC Red
11 +12V2 Yellow 23 +5 VDC Red
12VRS Yellow/White (24AWG) 5VRS Red/White (24AWG)
