Product Overview Intel
®
Entry Server Chassis SC5299-E TPS
Revision 3.1
Intel order number D37594-005
4
TP00866
E
G
H
I
F
J
A
B
D
C
A. Power supply (fixed power supply shown)
B. AC input power connector
C. I/O Ports
D. Expansion slot covers
E. Alternate external SCSI knockout
F. 120-mm system fan
G. Serial B port knockout
H. Location to install padlock loop
I. External SCSI knockout
J. Alternate Serial B port knockout
Figure 2. Rear Closed Chassis View of Intel
®
Entry Server Chassis SC5299-E
