Intel SC5299BRP User Manual

Product Overview Intel
®
Entry Server Chassis SC5299-E TPS
Revision 3.1
Intel order number D37594-005
2
This specification details the key features of the product. Reference documents listed at the
back of this document provide additional product specification details for the server boards,
backplanes, and power supplies validated for use with this chassis. Check the compatibility,
section on the support website for more details:
http://www.intel.com/p/en_US/support/highlights/server/sc5299-e
.
The following table summarizes the features for all chassis combinations:
Table 1. Intel
®
Entry Server Chassis SC5299-E UP, DP, BRP, and WS Features
Configuration SC5299UP SC5299DP SC5299BRP SC5299WS
Intel
®
Server
Board Support
Intel
®
Server Board
S3200SHV
Intel
®
Server Board
S3210SHLC
Intel
®
Server Board
S3210SHLX
Intel
®
Server Board
S3430GPV
Intel
®
Server Board
S5000VSA
Intel
®
Server Board
S5000PSL
Intel
®
Server Board
S5000XSL
Intel
®
Server Board
S3420GPLC
Intel
®
Server Board
S3420GPLX
Intel
®
Server Board
S5000VSA
Intel
®
Server Board
S5000PSL
Intel
®
Server Board
S5000XSL
Intel
®
Server Board
S3420GPLC
Intel
®
Server Board
S3420GPLX
Intel
®
Server Board
S5000XVN
Power Delivery 420-W PFC Intel
validated PSU with
integrated cooling fan.
550-W PFC Intel
validated PSU with
integrated cooling fan.
650-W PFC Intel
validated PSU with
integrated cooling fan.
One additional 650-W
PSU can be added for
redundancy.
670-W PFC Intel
validated PSU with
integrated cooling fan.
System Cooling One tool-less, 120-mm chassis fan. One tool-less, 120-mm
chassis fan. One tool-
less 92-mm drive bay
fan.
Peripheral Bays Two tool-less, multi-mount 5.25-in peripheral bays. One standard 3.5-in removable media peripheral
bay.
Drive Bays Includes one tool-less fixed drive bay. Supports
up to four hard drives.
Optional hot-swap tool-less drive bay is available.
Includes one tool-less
fixed drive bay for up to
six fixed drives.
Optional hot-swap tool-
less six-drive bay is
available.
PCI Slots 7 slots and support for 6 full-length with tail card guide
Form Factor 5.2U tower, convertible to 6U rack mount
Front Panel LEDs for NIC1, NIC2, HDD activity, power status, and system fault status.
Switches for power, NMI, and reset.
Integrated temperature sensor for fan speed management.
External front Two USB ports

Intel SC5299BRP Specifications

General

Brand	Intel
Model	SC5299BRP
Category	Chassis
Language	English
