Intermec EasyCoder 501 E – Installation & Operation Ed. 1 17
Chapter 3 Installation
Front View
At the front of the printer are the display window, the control lamps,
and a membrane-switch keyboard with 22 keys. These features
allow the operator to control the printer manually, in addition to
the remote control facilities offered by the Intermec Fingerprint
programing language and Intermec Shell.
There are also a connector for an optional cutter which replaces the
front door, an optional label taken sensor, and a slot for accessing an
optional memory card adapter.
The printed labels, tickets, or tags are presented at the front of
the print mechanism.
Side Door
Control Lamps
Display Window
Keyboard
Print Mechanism
Cutter Connector
Memory Card Slot
Front Door
(or optional cutter)
Label Taken Sensor
(option)
