Intermec EasyCoder 501 E User Manual

Intermec EasyCoder 501 E – Installation & Operation Ed. 1124
Appendix 1
Printing
Print Technique Direct Thermal and Thermal Transfer
1
Printhead Resolution 8 or 11.81 dots/mm (203.2 or 300 dpi) Quick-mount printhead
Print Speed (max) 100 to 200 mm/sec. (≈ 4 to 8 inches/sec.)
Print Width (8/11.81 dots/mm ), max. 104 mm (4.09 inches)/108.3 mm (4.26 inches) = 832/1280 dots
Print Length (8/11.81 dots/mm ) 1,250 mm (49.2 inches)/833 mm (32.8 inches)
Media Width (max) 120 mm (4.7 inches)
Media Roll Diameter (max) 205 mm (8.0 inches) Internal roll
Media Roll Core Diameter 38 to 40 mm (1.5 inches) or 76 mm (3 inches)
Ribbon Length, max 450 m (1,476 ft.) Intermec ribbons
Ribbon Width (max) 110 mm (4.3 inches)
Print Directions 4
Label Slack Absorber Yes
Modes of Operation
Tear-Off (Straight-through) Yes
Cut-Off Option With cutter
Peel-Off (Self-strip) Option With liner takeup
Internal Batch Takeup Option With liner takeup
Firmware
Operating System Intermec Fingerprint v6.14 Incl. Direct Protocol
Smooth Fonts Option (requires Scaleable Fonts Kit)
Built-in bitmap fonts (std) 10 Expandible 4 times
Built-in bar code symbologies (std) 32
Startup Program (std) Intermec Shell v4.01 Standard
Physical Measures
Dimensions (W x L x H) 275 x 480 x 239 mm (10.8 x 18.9 x 9.04 inches) Without cutter
Weight (excluding media and options) ≈ 15.0 kg (33 pounds)
Ambient Operating Temperature +5°C to +40°C (+41°F to +104°F)
Humidity 20 to 80% non-condensing
Sound Emission Level <60 dB(A)
Electronics
Microprocessor 32 bit RISC
On-board RAM memory Std. 512 Kbytes; Max. 2MB
1
Power Supply
Input Voltage 115/230 VAC (+10%/-15%), 2.6/1.3A, 60/50 Hz Manual switch
Maximum Power Consumption 300W
