Intermec EasyCoder 501 E – Installation & Operation Ed. 1 41
Chapter 5 Media Load
Internal Batch
Takeup
The EasyCoder 501 E printers can print on labels, tickets, tags,
and continuous stock in various forms. This chapter describes
the case when printed labels fitted on liner (backing paper) or
pre-perforated tickets and tags are wound up inside the printer. The
roll of printed labels, tickets, or tags can then be removed and be
handled manually. This requires an optional internal liner takeup
unit and a batch takeup guide.
The takeup hub can accommodate
1
/4 to
1
/3 of a full-size media
roll.
Internal batch takeup can be used for:
• Self-adhesive labels fi tted on liner
• Preperforated tickets with gaps
• Preperforated tickets with marks
1 2
Open the front and side doors.
Turn the printhead lift lever to “Load” posi-
tion.
