Intermec EasyCoder 501 E – Installation & Operation Ed. 1 21

Chapter 3 Installation

The print unit features a high performance 8 or 11.81 dots/mm

(203.2 or 300 dots/inch) thermal printhead with quick-mount ﬁ ttings

to facilitate replacement.

Print Unit

Printhead Lift Lever

Printhead Pressure Adjustment

Platen Roller

Tear Bar

Liner Drive Roller

Thermal Printhead

Printhead Lock
