Intermec EasyCoder 501 E – Installation & Operation Ed. 1 95
Chapter 10
Options
Introduction
The EasyCoder 501 E provides a high degree of fl exibility because
it has a modular design. By adding options to the basic printer, the
EasyCoder 501 E can be adapted for a variety of applications. Most
options can easily be installed by the operator, however a few should
be installed by an authorized service technician or are only available
as factory-installed options.
The cutter unit is fi tted on the same hinges as the front door, which
it replaces, and is connected by a single cable to the DIN-connector
on the printer’s front.
The cutter is intended to cut through continuous non-adhesive
paper strip or through the liner between labels. It must not cut
through any kind of adhesive, which would stick to the cutting
parts and rapidly render the cutter inoperable or even damage the
electric motor. Maximum thickness is 175 µm ( 175 grammes/m
2
)
for paper-based materials.
The cutter increases the printer’s total weight by approx. 1.0 kg
(=2.2 lbs) and its length by 28 mm (1.1 inches).
Cutter
