Intermec EasyCoder 501 E - Intermec Shell V.4.01 Enhanced, Main Diagram

Intermec EasyCoder 501 E – Installation & Operation Ed. 1 81
Chapter 9 Intermec Shell Startup Program
Intermec Shell v4.01 Enhanced, Diagram
Scaling of outline fonts in Speedo and TrueType formats.
Only displayed if a Scaleable Fonts Kit is fitted (option).
SHELL
TEST LABEL
SHELL
TESTFEED
SHELL
SER-COM RESET
SHELL
CLEAR RAM MEMORY
Perform a Testfeed, that is, feed out a blank copy and
autoadjust the label stop sensor.
Print a series of test labels in a loop.
Press Enter for each new label.
SHELL
REBOOT
Exit Shell and enter last selected application!
STD I/O CHANNEL
UART1
STD I/O CHANNEL
UART2
STD I/O CHANNEL
UART3
STD I/O CHANNEL
CENTRONICS
SEL. APPLICATION
optional applic.
SEL. APPLICATION
Fingerprint 6.14
SHELL
SETUP
See Setup Mode
Print a list of current setup values.
SHELL
PRINT SETUP
SEL. APPLICATION
WINDOWS DRIVER
ENTER=SHELL
5 sec. v.4.01
ENTER=SHELL
4 sec. v.4.01
ENTER=SHELL
3 sec. v.4.01
ENTER=SHELL
2 sec. v.4.01
ENTER=SHELL
1 sec. v.4.01
Last selected
application is started
Default:
Fingerprint 6.14
w. std I/O= "uart1:"
Last selected application is started
No action taken
POWER ON
Return to previous menu
in a stack of options.
Proceed to next menu
in a stack of options.
Accept displayed option
and proceed, or
execute displayed option.
Perform a Testfeed.
Can be used anywhere
in Intermec Shell.
Enter the Setup Mode.
Can be used anywhere
in Intermec Shell.
Legend:
SHELL
SEL. APPLICATION
SEL. APPLICATION
Direct Protocol
SEL. APPLICATION
optional applic.
SEL.APPL rom:
LINE_ALY.PRG
SETUP:
CONTRAST
PASSWORD:
491601
ARE YOU SURE ?
Y=ENTER/ N=F5
RAM MEMORY
CLEARED
SEL. APPLICATION
LABELSHOP
SHELL
FONT SCALING
Enter Terminal Setup
by transmitting T T T
or t t t to printer,
when menus marked with a
shade of grey are displayed!
ARE YOU SURE ?
Y=ENTER/ N=F5
SER-COM RESET
PERFORMED
SEL. APPLICATION
CURRENT APPL.
