Intermec EasyCoder 501 E – Installation & Operation Ed. 126
Chapter 4 Starting Up
Switching On the
Printer
Display Messages
at Startup
Do not start the printer before you have made the necessary
connections, inserted any memory card you want to use, and
checked that the printhead is lowered and an optional cutter is
in closed position.
Switch on the power by means of the On/Off switch on the rear plate.
The “Power” LED control lamp on the front panel lights up when
the power is on. Wait for a few moments, while the printer loads the
program and runs some self-diagnostic tests. If the printer is fi tted
with a cutter, it will rotate to home position. Finally, some kind of
message will appear in the display window.
After starting up the printer for the fi rst time, keep the power on
overnight to charge the memory backup battery.
The type of startup file running in the printer is indicated by
the message shown in the display window immediately after
startup.
Intermec Shell Enhanced Startup Program
ENTER=SHELL
5 sec. v.4.01
4 sec. v.4.01
3 sec. v.4.01
2 sec. v.4.01
1 sec. v.4.01
Refer to Chapter 8 for more information on Intermec Shell. The
digits in the lower right corner of the display indicate the version
of Intermec Shell.
No Intermec Shell Program Installed (non-standard printers)
Fingerprint
6.14
Refer to the documentation of the corresponding version of Intermec
Fingerprint for further information.
Custom-Made Application Program (non-standard printers)
Any other display messages than those illustrated above indicates that
the printer is running some custom-made, non-standard application
program, or that some error has occurred.
