4. Data transmission settings RS-232
52
ScanPlus 1800 - Installation Manual
active
\4A\60
RTS / CTS hardware protocol
- CTS is tested before transmission of each character - data is only transmitted when CTS is
activated
- RTS is activated before data is transmitted
- RTS can be deactivated after transmission of each character, after transmission of the whole
message, or after an RTS pulse which can be emitted when each character is transmitted
not active (*)
\47\5F\00\60
active, RTS idle after each character
\47\5F\01\60
active, RTS idle after whole message
\47\5F\03\60
active, RTS pulse on each character
\47\5F\02\60
