5. Symbologies Interleaved 2 of 5
96
ScanPlus 1800 - Installation Manual
French CIP HR
- French pharmaceutical industry
- only used for codes with 7 characters
checked and transmitted
\43\41\60
checked but not transmitted
\43\42\60
barcode length
= <barcode data> + [check digit]
- minimum length possible = 2 characters
- if the codes in your application have fixed lengths, use the "compose 1 or 2 or 3 fixed lengths"
option !!!
- Interleaved 2 of 5 always encodes an even number of characters
- for codes with an odd number of characters, you can add a last character printed as 5 narrow
bars (not transmitted)
compose 1 or 2 or 3 fixed lengths:
\43\44\60
- enter a number string and scan End Selection
for each length and scan End Selection twice to
finish (Appendix C)
- compose 1 or 2 or 3 fixed lengths provides the
best performance and security if the codes in
your application have fixed lengths
- minimum length possible = 2 characters
