3. Terminal / cash register used in your application predefined terminal selections
26
ScanPlus 1800 - Installation Manual
IBM 46xx cash registers
- predefined terminal selections also available with the terminal selector
- switch off the host system before you connect the cable !
- 3 green LED flashes at power-up
- setup is independent of the physical link with the cash register (you can configure for Port 9x or
Port 5x as required by the host)
Port 9x
\41\4A\01\2E\60
- you cannot send this parameter online to the
ScanPlus 1800 through RS-232 cable 0-
364032-00 !!! (send it to the setup sheet and
read the configuration code with your normal
IBM product cable connected)
Port 5x
\41\4A\01\2F\60
- you cannot send this parameter online to the
ScanPlus 1800 through RS-232 cable 0-364032-
00 !!! (send it to the setup sheet and read the
configuration code with your normal IBM product
cable connected)
