SERVICE MANUAL
Invacare
®
- Bora/Spectra XTR
66
• Pull the battery case socket / plug out of the
guide.
• The rear battery is only fitted with a battery
case socket at the front.
• The front battery is fitted with a battery case
socket at the front (flange central) and with a
battery case plug at the rear (flange flush).
• Note the fixing position of the battery and the
battery case sockets/plugs. The new battery
must be refitted in exactly the same position
as the old one.
• The batteries can be pulled upwards out of
the battery cases by their handles.
• Remove the terminal cover from the battery
terminals (1).
