Goodrive200 inverters Function codes
55
Function
code
Name
Detailed instruction of parameters
Default
value
The stronger the braking current, the bigger the
braking power. The DC braking current before
starting means the percentage of the rated
current of the inverter.
The setting range of P01.03: 0.0~100.0%
The setting range of P01.04: 0.00~50.00s
P01.04
The changing mode of the frequency during
start-up and running.
0:Linear type
The output frequency increases or decreases
linearly.
1:Reserved
0 ◎
P01.06
0: Decelerate to stop: after the stop command
becomes valid, the inverter decelerates to reduce
the output frequency during the set time. When
the frequency decreases to 0Hz, the inverter
stops.
1: Coast to stop: after the stop command
becomes valid, the inverter ceases the output
immediately. And the load coasts to stop at the
mechanical inertia.
0 ○
P01.09
Starting Starting frequency of DC braking: start the DC 0.00Hz
