FX-3R Maintenance Guide
15-4
Rev. 1.00
Figure 15-2-1 Disconnection of Air Tube and Solenoid Valve Connector
Mechanical valve
Solenoid valve
Manual switch
CN381
Solenoid valve connector
connection
Air tube connection
