Installing the ACX1000 or ACX1100 Router in the Rack
NOTE: The router can be installed horizontally in a rack or cabinet. For
additional installation options, contact JTAC.
To install the router in the rack (see Figure 21 on page 102):
CAUTION: Before front mounting the router in a rack, have a qualified
technician verify that the rack is strong enough to support the router's weight
(about 7 lb (3.2 kg)) and is adequately supported at the installation site.
NOTE: One person must be available to lift the router while another secures
it to the rack.
CAUTION: If you are mounting multiple units on a rack, mount the heaviest
unit at the bottom of the rack, and mount the other units from the bottom of
the rack to the top in decreasing order of the weight of the units.
1. Ensure that the rack is in its permanent location and is secured to the building. Ensure
that the installation site allows adequate clearance for both airflow and maintenance.
2. Position the router in front of the rack or cabinet.
3. Hold onto the bottom of the chassis, and carefully lift it so that the mounting brackets
contact the rack rails.
WARNING: To prevent injury, keep your back straight and lift with your
legs, not your back. Avoid twisting your body as you lift. Balance the load
evenly and be sure that your footing is solid.
4. Align the mounting brackets with the holes in the rack rails.
5. Install a mounting screw into each of the open mounting holes aligned with the rack,
starting from the bottom.
6. Visually inspect the alignment of the router. If the router is installed properly in the
rack, all the mounting screws on one side of the rack should be aligned with the
mounting screws on the opposite side, and the router should be level.
101Copyright © 2017, Juniper Networks, Inc.
Chapter 11: Installation Overview
