Management Port Connector Pinout Information for ACX Series Routers
The management port on an ACX Series router labeled MGMT uses an RJ-45 connector
to connect to a management device for out-of-band management.
The port uses an autosensing RJ-45 connector to support a 10/100Base-T connection.
Two LEDs indicate link/activity on the port and the administrative status of the port.
Table 26 on page 66 provides the pinout information for the RJ-45 connector for the
management port.
Table 26: Management Port Connector Pinout Information
DirectionDescriptionPin
In/OutTRD[0]-1
In/OutTRD[0]+2
In/OutTRD[1]-3
In/OutTRD[1]+4
In/OutTRD[2]-5
In/OutTRD[2]+6
In/OutTRD[3]-7
In/OutTRD[3]+8
Related
Documentation
Console/Auxiliary Port Connector Pinout on ACX Series Routers on page 65•
USB Port Specifications for an ACX Series Router
The following Juniper Networks USB flash drives have been tested and are officially
supported for the USB port on all ACX Series routers:
•
RE-USB-1G-S
•
RE-USB-2G-S
•
RE-USB-4G-S
CAUTION: Any USB memory product not listed as supported for ACX Series
routers has not been tested by Juniper Networks. The use of any unsupported
USB memory product could expose your ACX Series router to unpredictable
behavior. Juniper Networks Technical Assistance Center (JTAC) can provide
Copyright © 2017, Juniper Networks, Inc.66
ACX1000 and ACX1100 Universal Access Router
