Page #141 background imageLoading...
Page #141 background image
2. Plug one end of the replacement cable into the appropriate MGMT port.
3. Plug the other end of the cable into the network device.
Related
Documentation
Management Port Connector Pinout Information for ACX Series Routers on page 66
Replacing an ACX1000 or ACX1100 Fiber-Optic Cable
To replace a fiber-optic cable:
1.
Disconnecting an ACX1000 or ACX1100 Fiber-Optic Cable on page 123
2.
Connecting an ACX1000 or ACX1100 Fiber-Optic Cable on page 124
Disconnecting an ACX1000 or ACX1100 Fiber-Optic Cable
ACX Series routers have field-replaceable unit (FRU) optical transceivers to which you
can connect fiber-optic cables.
Before you begin disconnecting a fiber-optic cable from an optical transceiver installed
in an ACX Series router, ensure that you have taken the necessary precautions for safe
handling of lasers (see “General Laser Safety Guidelines for Juniper Networks Devices”
on page 171).
Ensure that you have the following parts and tools available:
A rubber safety cap to cover the transceiver
A rubber safety cap to cover the fiber-optic cable connector
To disconnect a fiber-optic cable from an optical transceiver installed in the router:
1. Disable the port in which the transceiver is installed by issuing the command:
[edit interfaces]
user@router# set interface-name disable
WARNING: Do not look directly into a fiber-optic transceiver or into the
ends of fiber-optic cables. Fiber-optic transceivers and fiber-optic cables
connected to transceivers emit laser light that can damage your eyes.
2. Carefully unplug the fiber-optic cable connector from the transceiver.
3. Cover the transceiver with a rubber safety cap.
123Copyright © 2017, Juniper Networks, Inc.
Chapter 16: Installing and Replacing Components
