Table 7: T1/E1 Port Features
DescriptionFeature
E1: 2.048 Mbps per channel
T1: 1.544 Mbps per channel
Line rate
TDM (SAToP) mode
ATM PWE3/ATM IMA Mode
Encapsulation
Superframe (D4)
Extended superframe (ESF)
Framed clear channel
Framing
T1/E1
T1 FDL
CSU
BERT
JIT
Diagnostic features
Category 5 shielded twisted pairCable
100-ohm RJ-48 connectorConnector
0/0/0 through 0/0/7Port numbering (hardware)
T1 framing (default): ct1-0/0/0 through ct1-0/0/7
E1 framing: ce1-0/0/0 through ce1-0/0/7
Port numbering (software)
Gigabit Ethernet RJ-45 Ports
Each ACX1000 and ACX1100 router has twelve Gigabit Ethernet RJ-45 ports.
Table 8 on page 33 describes the ports in more detail.
Table 8: RJ-45 Port Features
DescriptionFeature
•
10BASE-T Copper
•
100BASE-T
•
1000BASE-T
Supported standards
Category 5Cable
RJ-45Connector
33Copyright © 2017, Juniper Networks, Inc.
Chapter 2: Chassis Components and Descriptions
