Grounding Cable Specifications
You must provide one grounding cable that meets the following specifications: 6-AWG
(4.11 mm
2
), minimum 90°C wire, or as required by the local code.
Related
Documentation
Connecting the ACX1000 or ACX1100 Router to Earth Ground on page 103•
• Preventing Electrostatic Discharge Damage to an ACX1000 or ACX1100 Router on
page 158
ACX1100 AC Power Specifications
Table 21 on page 59 lists the AC power system electrical specifications.
Table 21: AC Power System Electrical Specifications
SpecificationItem
Operating range: 100 to 240 VACAC input voltage
50 to 60 Hz (nominal)AC input line frequency
2 A (100 VAC) or 1 A (240 VAC)AC system current rating
85 WAC system input power
70 WMaximum AC power supply output
NOTE: We recommendthatyouuse a dedicatedcustomer sitecircuitbreaker
rated for 2 A (100 VAC) or 1 A (240 VAC), or as required by local code. Doing
so enables you to operate the router in any configuration without upgrading
the power infrastructure.
Related
Documentation
ACX1100 AC Power Cord Specifications on page 59•
ACX1100 AC Power Cord Specifications
Each AC power supply has a single AC appliance inlet that requires a dedicated AC power
feed. Most sites distribute power through a main conduit that leads to frame-mounted
power distribution panels, one of which can be located at the top of the rack that houses
the router. An AC power cord connects each power supply to the power distribution panel.
You can order detachable AC power cords, each approximately 8 ft (2.5 m) long that
supply AC power to the router. The C15 appliance coupler at the female end of the cord,
as described by International Electrotechnical Commission (IEC) standard 60320, inserts
59Copyright © 2017, Juniper Networks, Inc.
Chapter 8: Planning Power Requirements
