Table 8: SRX100 Services Gateway Front Panel LEDs
UsageDescriptionComponentNumber
The Alarm LED can be used
to gather information on
major or minor alarms or to
determine if the device is
functioning normally.
The Alarm LED has the
following indicator colors:
Red and steadily on
indicates a major alarm.
Amber and steadily on
indicates a minor alarm.
Off indicates that there
are currently no alarms.
Alarm LED1
The Power LED can be used
to determine if the device is
receiving power.
The Power LED has the
following indicator colors:
Green and steadily on
indicates that the device
is functioning normally.
Amber and steadily on
indicates that the power
button has been pressed
and quickly released.
The device is gracefully
shutting down.
Off indicates that the
device is not receiving
power.
Power LED2
The HA LED can be used to
determine if chassis
clustering is enabled on the
device.
The HA LED has the following
indicator colors:
Green and steadily on
indicates that all chassis
clustering links are
available.
Red and steadily on
indicates that the chassis
clustering links are not
working as expected.
Amber and steadily on
indicates that some
chassis clustering links
are not working as
expected.
Off indicates that chassis
clustering is not enabled.
NOTE: Chassis clustering is
not supported in this release.
HA LED3
SRX100 Services Gateway LEDs 11
