ULTRAFLOW®54(H)/(J)
KamstrupA/S∙TechnicalDescription∙5512‐1554_J1_GB_04.2018
11
4 Ordering details
4.1 ULTRAFLOW
®
54 (H)/(J)
q
p
q
i
q
s
Length Meter factor
[m³/h] [m³/h] [m³/h] [mm] [pulses/l]
65-5- CAHA -XXX 0.6 0.006 1.2 100:1 G¾B (R½) 16/25 110 300 Brass
65-5- CAHD -XXX 0.6 0.006 1.2 100:1 G1B (R¾) 16/25 130 300 Brass
(65-5- CAHF -XXX) 0.6 0.006 1.2 100:1 G1B (R¾) 16/25 190 300 Brass
65-5- CDHA -XXX 1.5 0.015 3 100:1 G¾B (R½) 16/25 110 100 Brass
65-5- CDHC -XXX 1.5 0.015 3 100:1 G¾B (R½) 16/25 165 100 Brass
(65-5- CDH1 -XXX) 1.5 0.015 3 100:1 G1B (R¾) 16 110 100 Brass
65-5- CDHD -XXX 1.5 0.015 3 100:1 G1B (R¾) 16/25 130 100 Brass
65-5- CDHF -XXX 1.5 0.015 3 100:1 G1B (R¾) 16/25 190 100 Brass
(65-5- CEHD -XXX) 2.5 0.025 5 100:1 G1B (R¾) 16/25 130 60 Brass
65-5- CEHF -XXX 2.5 0.025 5 100:1 G1B (R¾) 16/25 190 60 Brass
65-5- CGJG -XXX 3.5 0.035 7 100:1 G1
¼
B (R1) 16/25 260 50 Brass
(65-5- CGJ6 -XXX) 3.5 0.035 7 100:1 G1
¼
B (R1) 16/25 135 50 Brass
(65-5- CGJ7 -XXX) 3.5 0.035 7 100:1
G1
¼
B (R1)
16/25 150 50 Brass
65-5- CHJG -XXX 6 0.060 12 100:1 G1
¼
B (R1) 16/25 260 25 Brass
65-5- CHJH -XXX 6 0.060 12 100:1 G1
½
B (R1
¼
) 16/25 260 25 Brass
(65-5- CHJ6 -XXX) 6 0.060 12 100:1 G1
¼
B (R1) 16/25 135 25 Brass
(65-5- CHJ7 -XXX) 6 0.060 12 100:1
G1
¼
B (R1)
16/25 150 25 Brass
65-5- CJJJ -XXX 10 0.100 20 100:1 G2B (R1½) 16/25 300 15 Brass
(65-5- CJJ8 -XXX) 10 0.100 20 100:1
G2B (R1
½
)
16/25 200 15 Brass
*
XXX - code for final assembly, approvals etc. - determined by Kamstrup. A few variants may not be available in national approvals.
Type number * Connection
Dynamic
range
q
p
:q
i
PN
Material
(Housing)
Table 3. Type numbers of ULTRAFLOW
®
54 (H)/(J).
When ordering ULTRAFLOW
®
and MULTICAL
®
separately, please also consult the respective Technical descriptions
of MULTICAL
®
602/603/801 (5512-931_GB/5512-2029_GB/5512-571_GB) for flow meter coding.
4.2 Accessories for ULTRAFLOW
®
1 pc. 2 pcs.
DN15 R ½ G ¾ - 6561-323
DN20 R ¾ G 1 - 6561-324
DN25 R 1 G 5/4 6561-325 -
DN32 R 5/4 G 1½ 6561-314 -
DN40 R1
½
G 2 6561-315 -
Size Nipple Union
Type No.
Couplings
Table 4. Couplings including gaskets (PN16).
Size (union) T
y
pe No.
G ¾ 2210-061
G 1 2210-062
G 5/4 2210-063
G 1½ 2210-064
G 2 2210-065
Gaskets for couplings
Table 5. Gaskets.
