ULTRAFLOW®54(H)/(J)
14
KamstrupA/S∙TechnicalDescription∙5512‐1554_J1_GB_04.2018
4.3.5 Accessories for Pulse Transmitter and Pulse Divider
Please note that not all article numbers in Table 8 can be directly ordered, some must be ordered via our service
department.
65-000-000-2000 D-cell lithium battery with two-pole connector
3026-477
1)
Fitting for D-cell battery
Enclosed if battery supply
or “No supply” is selected
1650-157
1)
Plug for cable connection
Enclosed if battery supply
or “No supply” is selected
65-000-000-7000
2)
230 VAC supply module
65-000-000-8000
2)
24 VAC supply module
5000-290 Cable between supply module and output module
Enclosed if supply module
is selected
5000-286 24/230 VAC power cable Optional
6699-012
Output module (Y=2), galvanically separated
5550-1062
6699-013
Output module (Y=3), galvanically separated, “Low power”
5550-1219
5000-333 2.5 m silicone cable (3-wire) Optional
5000-259 5 m silicone cable (3-wire) Optional
5000-270 10 m silicone cable (3-wire) Optional
3026-207 Bracket for wall munting Optional
Article number Description
Note
(when ordering Pulse
Transmitter/Pulse Divider)
1)
Obligatory when changing from mains supply module to battery supply.
2)
Including 5000-290.
Table 8. Accessories for Pulse Transmitter and Pulse Divider.
4.3.6 Cables
Pulse Transmitter and Pulse Divider are available with signal cable lengths 2.5; 5 or 10 m. The signal cable is
mounted from the factory.
If 24/230 VAC supply module is selected, Pulse Transmitter and Pulse Divider are optionally available with mains
supply cable. The cable is mounted from the factory.
4.3.7 Cable Extender Box
The Cable Extender Box (Type 6699-036) allows a signal cable length of up to max. 30 m between ULTRAFLOW
®
and
MULTICAL
®
. The device supports flow-Info, but it does not provide galvanic separation (for further details see
paragraph 4.3.1). The Cable Extender Box (Type 6699-036) must be ordered separately.
Kamstrup offers signal cables with a length of 2.5 m (Type 5000-333), 5 m (Type 5000-259) and 10 m (Type 5000-
270), which can be ordered separately. In combination with the signal cables of 2.5m, 5 m or 10 m typically
delivered with ULTRAFLOW
®
, different total length of up to 20 m between ULTRAFLOW
®
and MULTICAL
®
can be
achieved. With signal cables of different length but equal quality as Kamstrup’s signal cables, it is possible to find
individual solutions for the cable extension up to max. 30 m between ULTRAFLOW
®
and MULTICAL
®
. For electrical
connection, see paragraph 7.6.3.
