10 METERTOOL
10.1 Introduction
METERTOOL is a collection of programs used for servicing Kamstrup heat meters.
”METERTOOL for ULTRAFLOW
®
X4” is Windows
®
-based software. In combination with a PC and interface the software
makes it possible to adjust ULTRAFLOW
®
X4.
”METERTOOL for ULTRAFLOW
®
X4” has been developed to provide laboratories with simple and efficient access to
programming/adjusting ULTRAFLOW
®
X4. Furthermore, it is used for programming the Pulse Divider 66-99-607.
10.2 System requirements for PC
METERTOOL requires minimum Windows XP SP3, Windows Vista or Windows 7 (32-bits or 64-bits) or newer as well
as Microsoft Internet Explorer 5.01.
Minimum requirements:
Pentium 4 or equivalent (Atom processor/netbooks/mini PCs are not supported).
2 GB RAM
10 GB HD
Display resolution 1024 x 768
USB and CD-ROM drive
Printer installed
Administrator rights to the PC are required in order to install and use the programs.
The programs must be installed under the login subsequently using the programs.
10.2.1 Interface
The following interfaces can be used:
Interface for Type No. Description
ULTRAFLOW
®
54 66-99-141 Cable with USB connection to PC and 4-pole connector for ULTRAFLOW
®
54 and Pulse Divider 66-99-907.
ULTRAFLOW
®
54 (H) 66-99-024 Cable with USB connection for PC and 4-pole connection for
ULTRAFLOW
®
54 (H).
ULTRAFLOW
®
14/24 66-99-002 Adapter for connection of ULTRAFLOW
®
14/24. Plugged onto 66-99-141.
ULTRAFLOW
®
34 66-99-006 Adapter for connection of ULTRAFLOW
®
34. Plugged onto 66-99-141.
Pulse Divider 66-99-140 Cable with serial plug for PC and 8-pole plug for Pulse Divider 66-99-607.
Table 24. Interfaces for communication
Note: The supply to ULTRAFLOW
®
and/or Pulse Divider, if any, must be disconnected during programming. The
meter is powered via the connected communication interface.
The USB Interface (66-99-141 and 66-99-024) includes a converter box, which secures galvanic separation of the
supply for the flow sensor.
In order to mount the plug in the flow sensor, the sealing cover must be removed. If the sensor is used where
verification is required, an authorised laboratory must re-verify and reseal the sensor before it is remounted. The
positions of laboratory labels and year marks appear from paragraph 9.7.
