ULTRAFLOW®54(H)/(J)
74
KamstrupA/S∙TechnicalDescription∙5512‐1554_J1_GB_04.2018
10.4.6 Pulse Configuration DN150-DN300
Programming of meter factor and pulse duration for ULTRAFLOW
®
54 DN150-300. ”Pulse Configuration DN150-
DN250” is used for adapting the pulse signal to match calculator and other equipment, e.g. if ULTRAFLOW
®
is
connected to a calculator, which does not support Kamstrup's quick pulses. See Table 27 for valid programming
options.
Open "Pulse Configuration DN150-DN250".
”qp”: Based on the programmed
standard flow curve.
”Meter factor”: Only the valid meter factors
are available.
”Pulse duration”: Only the valid pulse
durations are available.
”Write”: Programs ULTRAFLOW
®
54
DN150-300 according to
the selected values.
