ULTRAFLOW®54(H)/(J)
KamstrupA/S∙TechnicalDescription∙5512‐1554_J1_GB_04.2018
73
q
p
Pulse facto
r
Pulse factor Divider Pulse factor Divider
[m³/h] [imp/l] [l/Pulse] [l/Pulse]
0.6 300 1 300 2.5 750
1.5 100 1 100 2.5 250
2.5 60 1 60 2.5 150
3 50 1 50 2.5 125
3.5 50 1 50 2.5 125
6 25 1 25 25 625
10 25 1 25 25 625
10 15 1 15 25 375
15 10 10 100 25 250
25 10 10 100 25 250
25 6 10 60 25 150
40 5 10 50 25 125
60 2.5 10 25 250 625
100 1.5 10 15 250 375
150 1 100 100 250 250
2500.610060250150
4000.410040250100
600 0.25 100 25 2500 625
1000 0.25 100 25 2500 625
ULTRAFLOW
®
Pulse Divider & Pulse Divider &
11EVL (pulse duration 50 ms) 1EVL (pulse duration 100 m
s
Table 26. Pulse division table for use together with Kamstrup EVL
For other variants, please see installation guide for Pulse Divider, Kamstrup Document No. 5511-727.
10.4.5 Pulse Divider type no. 66-99-907
Readout and programming of Pulse Divider, type no. 66-99-907, is not supported by the existing version of
METERTOOL UFx4 (rev. G1).
Instead we refer to METERTOOL HCW. See paragraph 11.
