19-164 Return to Section Topics 2600AS-901-01 Rev. B / September 2008
Section 19: Remote Commands Series 2600A System SourceMeter® Instruments Reference Manual
status.operation.calibrating.condition
status.operation.calibrating.enable
status.operation.calibrating.event
status.operation.calibrating.ntr
status.operation.calibrating.ptr
Attribute Operation status calibration summary register set.
Default 0
TSP-Link
accessibility
This attribute can be accessed from a remote TSP-Link node.
Usage Reads condition, enable, event, NTR, and PTR registers:
operreg = status.operation.calibrating.condition
operreg = status.operation.calibrating.enable
operreg = status.operation.calibrating.event
operreg = status.operation.calibrating.ntr
operreg = status.operation.calibrating.ptr
Writes to enable, NTR, and PTR registers:
status.operation.calibrating.enable = operreg
status.operation.calibrating.ntr = operreg
status.operation.calibrating.ptr = operreg
Set operreg to one of the following values:
0 Clears all bits.
status.operation.calibrating.SMUA Sets SMUA bit (B1).
status.operation.calibrating.SMUB Sets SMUB bit (B2).
operreg can also be set to the decimal weight of the bit to be set. Examples:
To set bit B1 (SMUA), set operreg to 2 (2
1
).
To set bit B2 (SMUB), set operreg to 4 (2
2
).
To set both bits, set operreg to the sum of the decimal weights of both bits.
To set bits B1 and B2, set operreg to 6 (2 + 4).
Remarks • These attributes are used to read or write to the operation status calibration summary registers.
• Reading a status register returns a value. The binary equivalent of the returned value indicates
which register bits are set. The least significant bit of the binary number is bit 0, and the most
significant bit is bit 15.
• For example, assume value 6 is returned for the enable register. The binary equivalent is
0000000000000110. This value indicates that bit B1(SMUA) and bit B2 (SMUB) are set.
• The used bits of the operation status calibration summary registers are described as follows:
• Bit B1, SMUA: Set bit indicates the enabled CAL bit for the SMU A operation register is set.
• Bit B2, SMUB: Set bit indicates the enabled CAL bit for the SMU B operation register is set.
Details See Operation Event Registers in Appendix C.
Example Sets the SMUA bit of the operation status calibration summary enable register:
status.operation.calibrating.enable =
status.operation.calibrating.SMUA
status.operation.instrument.condition
status.operation.instrument.enable
status.operation.instrument.event
status.operation.instrument.ntr
status.operation.instrument.ptr
