19-172 Return to Section Topics 2600AS-901-01 Rev. B / September 2008
Section 19: Remote Commands Series 2600A System SourceMeter® Instruments Reference Manual
status.operation.instrument.lan.trigger_overrun.condition
status.operation.instrument.lan.trigger_overrun.enable
status.operation.instrument.lan.trigger_overrun.event
status.operation.instrument.lan.trigger_overrun.ntr
status.operation.instrument.lan.trigger_overrun.ptr
Attribute Operation status LAN trigger overrun register set.
Default 0
TSP-Link
accessibility
This attribute can be accessed from a remote TSP-Link node.
Usage Reads condition, enable, event, NTR, and PTR registers:
operreg = status.operation.instrument.lan.trigger_overrun.condition
operreg = status.operation.instrument.lan.trigger_overrun.enable
operreg = status.operation.instrument.lan.trigger_overrun.event
operreg = status.operation.instrument.lan.trigger_overrun.ntr
operreg = status.operation.instrument.lan.trigger_overrun.ptr
Writes to enable, NTR, and PTR registers:
status.operation.instrument.lan.trigger_overrun.enable = operreg
status.operation.instrument.lan.trigger_overrun.ntr = operreg
status.operation.instrument.lan.trigger_overrun.ptr = operreg
Set operreg to one of the following values:
0 Clears all bits.
status.operation.instrument.lan.trigger_overrun.LAN1 Sets LAN1 bit (B1)
status.operation.instrument.lan.trigger_overrun.LAN2 Sets LAN2 bit (B2)
status.operation.instrument.lan.trigger_overrun.LAN3 Sets LAN3 bit (B3)
status.operation.instrument.lan.trigger_overrun.LAN4 Sets LAN4 bit (B4)
status.operation.instrument.lan.trigger_overrun.LAN5 Sets LAN5 bit (B5)
status.operation.instrument.lan.trigger_overrun.LAN6 Sets LAN6 bit (B6)
status.operation.instrument.lan.trigger_overrun.LAN7 Sets LAN7 bit (B7)
status.operation.instrument.lan.trigger_overrun.LAN8 Sets LAN8 bit (B8)
operreg can also be set to the decimal weight of the bit to be set. Examples:
To set bit B1 (LAN1), set operreg to 2 (2
1
).
To set bit B5 (LAN5), set operreg to 32 (2
5
).
To set two bits, set operreg to the sum of the decimal weights of both bits:
To set bits B1 and B5, set operreg to 34 (2 + 32).
