Series 2600A System SourceMeter® Instruments Reference Manual Section 19: Remote Commands
Remarks • These attributes are used to read or write to the operation status LAN trigger overrun registers.
• Reading a status register returns a value. The binary equivalent of the returned value indicates
which register bits are set. The least significant bit of the binary number is bit 0, and the most
significant bit is bit 15.
• For example, assume value 6 is returned for the enable register. The binary equivalent is
0000000000000110. This value indicates that bit B1 (LAN1) and bit B2 (LAN2) are set.
• The used bits of the operation status LAN trigger overrun registers are described as follows:
• Bit B1, LAN1: Set bit indicates LAN trigger 1 generated an action overrun when triggered to
generate a trigger packet.
• Bit B2, LAN2: Set bit indicates LAN trigger 2 generated an action overrun when triggered to
generate a trigger packet.
• Bit B3, LAN3: Set bit indicates LAN trigger 3 generated an action overrun when triggered to
generate a trigger packet.
• Bit B4, LAN4: Set bit indicates LAN trigger 4 generated an action overrun when triggered to
generate a trigger packet.
• Bit B5, LAN5: Set bit indicates LAN trigger 5 generated an action overrun when triggered to
generate a trigger packet.
• Bit B6, LAN6: Set bit indicates LAN trigger 6 generated an action overrun when triggered to
generate a trigger packet.
• Bit B7, LAN7: Set bit indicates LAN trigger 7 generated an action overrun when triggered to
generate a trigger packet.
• Bit B8, LAN8: Set bit indicates LAN trigger 8 generated an action overrun when triggered to
generate a trigger packet.
Details See Operation Event Registers in Appendix C.
Example Sets the LAN1 bit of the operation status LAN trigger overrun enable register:
status.operation.instrument.lan.trigger_overrun.enable =
status.operation.instrument.lan.trigger_overrun.LAN1
