19-180 Return to Section Topics 2600AS-901-01 Rev. B / September 2008
Section 19: Remote Commands Series 2600A System SourceMeter® Instruments Reference Manual
Remarks • These attributes are used to read or write to the operation status trigger timer overrun registers.
• Reading a status register returns a value. The binary equivalent of the returned value indicates
which register bits are set. The least significant bit of the binary number is bit 0, and the most
significant bit is bit 15.
• The used bits of the operation status trigger timer overrun registers are described as follows:
• Bit B1, TMR1: Set bit indicates Timer 1 generated an action overrun because it was still
processing a delay from a previous trigger when a new trigger was received.
• Bit B2, TMR2: Set bit indicates Timer 2 generated an action overrun because it was still
processing a delay from a previous trigger when a new trigger was received.
• Bit B3, TMR3: Set bit indicates Timer 3 generated an action overrun because it was still
processing a delay from a previous trigger when a new trigger was received.
• Bit B4, TMR4: Set bit indicates Timer 4 generated an action overrun because it was still
processing a delay from a previous trigger when a new trigger was received.
• Bit B5, TMR5: Set bit indicates Timer 5 generated an action overrun because it was still
processing a delay from a previous trigger when a new trigger was received.
• Bit B6, TMR6: Set bit indicates Timer 6 generated an action overrun because it was still
processing a delay from a previous trigger when a new trigger was received.
• Bit B7, TMR7: Set bit indicates Timer 7 generated an action overrun because it was still
processing a delay from a previous trigger when a new trigger was received.
• Bit B8, TMR8: Set bit indicates Timer 8 generated an action overrun because it was still
processing a delay from a previous trigger when a new trigger was received.
Details See Operation Event Registers in Appendix C.
Example Sets the Timer 3 bit of the operation status trigger timer overrun enable register:
status.operation.instrument.trigger_timer.trigger_overrun.enable =
status.operation.instrument.trigger_timer.trigger_overrun.TMR3
