Keithley 2600a series User Manual

2600AS-901-01 Rev. B / September 2008 Return to Section Topics 19-201
Series 2600A System SourceMeter® Instruments Reference Manual Section 19: Remote Commands
status.system3.condition
status.system3.enable
status.system3.event
status.system3.ntr
status.system3.ptr
Attribute TSP-Link system summary register 3 set.
Default 0
TSP-Link
accessibility
This attribute can be accessed from a remote TSP-Link node.
Usage Reads condition, enable, event, NTR, and PTR registers:
enablereg = status.system3.condition
enablereg = status.system3.enable
enablereg = status.system3.event
enablereg = status.system3.ntr
enablereg = status.system3.ptr
Writes to enable, NTR, and PTR registers:
status.system3.enable = enablereg
status.system3.ntr = enablereg
status.system3.ptr = enablereg
Set enablereg to one of the following values:
0 Clears all bits.
status.system3.EXTENSION_BIT Sets EXT bit (B0).
status.system3.EXT Sets EXT bit (B0).
status.system3.NODE29 Sets node bit (B1)
status.system3.NODE30 Sets node bit (B2)
status.system3.NODE31 Sets node bit (B3)
status.system3.NODE32 Sets node bit (B4)
status.system3.NODE33 Sets node bit (B5)
status.system3.NODE34 Sets node bit (B6)
status.system3.NODE35 Sets node bit (B7)
status.system3.NODE36 Sets node bit (B8)
status.system3.NODE37 Sets node bit (B9)
status.system3.NODE38 Sets node bit (B10)
status.system3.NODE39 Sets node bit (B11)
status.system3.NODE40 Sets node bit (B12)
status.system3.NODE41 Sets node bit (B13)
status.system3.NODE42 Sets node bit (B14)
Remarks • In an expanded system (TSP-Link), These attributes are used to read or write to the system
summary register 3 registers.
• Reading a system summary register 3 register returns a numeric value whose binary equivalent
indicates which register bits are set. The bits of the system summary register 3 register are
identified as follows:
• For example, assume value 9 is returned for the enable register. The binary equivalent is
0000000000001001. This value indicates that bit 0 (EXT) and bit 3 (Node 31) are set.
Details See System Summary Event Registers in Appendix C.
Also see
status.system, status.system2, status.system4, status.system5
Example Sets the extension bit of the system summary register 3 enable register:
status.system3.enable = status.system3.EXT
Bit B0 - EXT bit
Bit B1 - Node 29
Bit B2 - Node 30
Bit B3 - Node 31
Bit B4 - Node 32
Bit B5 - Node 33
Bit B6 - Node 34
Bit B7 - Node 35
Bit B8 - Node 36
Bit B9 - Node 37
Bit B10 - Node 38
Bit B11 - Node 39
Bit B12 - Node 40
Bit B13 - Node 41
Bit B14 - Node 42
Bit B15 - Not used
