Data store programming example
Table 8-2 summarizes the commands for basic data store operation. These commands set up
the SourceMeter as follows:
• Reading source: raw readings.
• Number of points: 10.
• Acquired data: buffer readings, mean (average), and standard deviation.
NOTE You can determine when the buffer is full by reading the appropriate status register
bit. See Section 14 for details on the status structure.
Table 8-2
Data store example
Command Description
*RST
:SOUR:VOLT 10
:TRAC:FEED SENS
:TRAC:POIN 10
:TRAC:FEED:CONT NEXT
:TRIG:COUN 10
:OUTP ON
:INIT
:TRACE:DATA?
:CALC3:FORM MEAN
:CALC3:DATA?
:CALC3:FORM SDEV
:CALC3:DATA?
Restore GPIB defaults.
Source 10V.
Store raw readings in buffer.
Store 10 readings in buffer.
Enable buffer.
Trigger count = 10.
Turn on output.
Trigger readings.
Request raw buffer readings.
Select mean buffer statistic.
Request buffer mean data.
Select standard deviation statistic.
Request standard deviation data.
