Getting Started 1-31
Table 1-9
Sweep, digits, speed, and data store configuration menus
Configuration menu item Description
CONFIG SWEEP Configure sweeps.
CONFIGURE SWEEPS
TYPE Select sweep type.
STAIR Staircase sweep, program START, STOP, STEP.
LOG Log sweep, program START, STOP, # POINTS.
CUSTOM Custom sweep, program parameters.
# POINTS Program number of sweep points.
ADJUST POINTS Set individual point values.
INIT Set first point value.
SRC MEMORY Source memory sweep, set parameters.
START Set first point value.
# POINTS Set number of points.
SWEEP COUNT Set sweep count.
FINITE Program sweep count value.
INFINITE Never-ending sweep.
SOURCE RANGING Set sweep ranging mode.
BEST FIXED Best fixed range based on maximum value.
AUTO RANGE Auto range during sweep.
FIXED Set fixed source range.
CONFIG DIGITS Set display number of digits.
DISPLAY DIGITS Select 3.5, 4.5, 5.5, or 6.5.
CONFIG SPEED Set measurement speed.
SPEED ACCURACY MENU
FAST Fast speed.
MED Medium speed.
NORMAL Normal.
HI ACCURACY Maximum accuracy.
OTHER Program NPLCs (number power line cycles).
CONFIG STORE Configure data store timestamp.
STORE TIMESTAMP
ABSOLUTE Absolute timestamp.
DELTA Delta timestamp.
