Table 1-6
Source and range configuration menus
Configuration menu item Description
CONFIG SOURCE V Configure V source.
CONFIGURE V SOURCE
PROTECTION Select voltage protection.
DELAY Program delay between source and measure.
AUTO DELAY Enable/disable auto delay.
DISABLE
ENABLE
GUARD Select ohms or cable guarding.
OHMS
CABLE
TRIG Control triggered source.
CONTROL Enable/disable triggered source.
DISABLE
ENABLE
SCALE FACTOR Program scale factor.
CONFIG SOURCE I Configure I source
CONFIGURE I SOURCE
GUARD Select ohms or cable guarding.
OHMS
CABLE
DELAY Program delay between source and measure.
AUTO DELAY Enable/disable auto delay.
DISABLE
ENABLE
TRIG Control triggered source.
CONTROL Enable/disable triggered source.
DISABLE
ENABLE
SCALE FACTOR Program scale factor.
CONFIG ▲ RANGE Program upper range limit.
CONFIG ▼ RANGE Program lower range limit.
CONFIG AUTO RANGE
AUTO RANGE TYPE Select auto range type.
SINGLE SRC MTR Select single SourceMeter operation.
MULTIPLE Select multiple SourceMeter, program soak time.
