Getting Started 1-27
Table 1-5
Measurement configuration menus
Configuration menu item Description
CONFIG MEAS Ω Configure ohms measure.
CONFIG OHMS
SOURCE Select manual or auto source for ohms.
MANUAL
AUTO
GUARD Select ohms or cable guard.
OHMS
CABLE
SRC RDBK Enable/disable source readback.
DISABLE
ENABLE
OFFSET COMPENSATION Enable/disable offset compensation.
DISABLE
ENABLE
CONFIG FCTN Configure functions.
CONFIGURE FUNCTION
POWER Enable power function.
OFF COMP OHMS Enable offset-compensated ohms, program parameters.
VOLT-COEFF Enable voltage coefficient, program parameters.
VAR ALPHA Enable varistor alpha, program parameters.
%DEV Enable percent deviation, program parameters.
