Keithley 6430 User Manual

Limit Testing 11-19
Remote limit testing
Limit commands
Table 11-1 summarizes remote commands to control limit testing. See CALCulate2 and
SOURce2 in Section 17 for more details on these commands.
T a ble 11-1
Limit commands
Command* Description*
:CALCulate2:FEED <name> Select limit test input path (name = CALCulate[1],
VOLTage, CURRent, or RESistance).
:CALCulate2:DATA? Acquire limit test data.
:CALCulate2:LIMit:COMPliance:FAIL <name> Set Limit 1 fail condition. Name = IN (fail into
compliance) or OUT (fail out of compliance).
:CALCulate2:LIMitX:LOWer <n> Specify lower Limit X; X = 2, 3, 5-12 (n = limit).
:CALCulate2:LIMitX:UPPer <n> Specify upper Limit X; X = 2, 3, 5-`2 2 (n = limit).
:CALCulate2:LIMit[1]:COMPliance:SOURce2 <NRf> |
<NDN>
Specify limit 1 fail bit pattern.
(NRf | NDN = pattern).
:CALCulate2:LIMitX:LOWer:SOURce2 <NRf> | <NDN> Specify lower Limit X fail bit pattern for grading
mode; X = 2, 3, 5-12 (NRf | NDN = bit pattern).
:CALCulate2:LIMitX:UPPer:SOURce2 <NRf> | <NDN> Specify upper Limit X fail bit pattern for grading
mode; X = 2, 3, 5-12 (NRf = bit pattern).
:CALCulate2:LIMitX:PASS:SOURce2 <NRf> | <NDN> Specify pass pattern for sorting mode
(NRf | NDN = bit pattern).
:CALCulate2:LIMit[1]:STATe <state> Enable/disable Limit 1 test (state = ON or OFF).
:CALCulate2:LIMitX:STATe <state> Enable/disable Limit X test; X = 2, 3, 5-12
(state = ON or OFF).
:CALCulate2:LIMit[1]:FAIL? Query Limit 1 test result (0 = pass, 1 = fail).
:CALCulate2:LIMitX:FAIL? Query Limit X test result; X = 2, 3, 5-12
(0 = pass, 1 = fail).
:CALCulate2:CLIMits:PASS:SOURce2 <NRf> | <NDN> Specify pass bit pattern (NRf | NDN = pattern).
Sorting mode only if limits 2, 3 and 5-12
disabled.
:CALCulate2:CLIMits:FAIL:SOURce2 <NRf> | <NDN> Specify fail bit pattern for sorting mode
(NRf | NDN = pattern).
:CALCulate2:CLIMits:PASS:SMLocation <location> Specify pass source memory location. Location =
NRf (memory #) or NEXT (next location).
:CALCulate2:CLIMits:FAIL:SMLocation <location> Specify fail source memory location. (Location =
NRf (memory #) or NEXT (next location).
:CALCulate2:CLIMits:BCONtrol <name> Control I/O port pass/fail update. Name =
IMMediate (at failure) or END (end of sweep).
:CALCulate2:CLIMits:CLEar Clear test results, reset I/O port.
:CALCulate2:CLIMits:CLEar:AUTO <state> Enable/disable auto-clear (state = ON or OFF).
:CALCulate2:CLIMits:MODE <name> Select Digital I/O control mode (name = GRADing
or SORTing).
